Important
• Do not remove the Maintenance Cartridge during initialization immediately after replacing the Maintenance
Cartridge. The Maintenance Cartridge may become damaged.
7
Close the Maintenance Cartridge Cover.
Note
• If you did not perform the operation in Access the menu for Maintenance Cartridge replacement, this is
the end of the procedure and you do not need to press the OK key in the next step.
8
Press the OK button.
Checking the Remaining Maintenance Cartridge Capacity
Checking the Remaining Maintenance Cartridge Capacity
The Maintenance Cartridge absorbs excess ink from borderless printing, printhead cleaning, and other processes. You
can confirm the remaining capacity of the Maintenance Cartridge by checking the Maintenance Cartridge capacity
shown on the Display Screen.
To check remaining Maintenance Cartridge capacity, access the Tab Selection screen on the Control Panel and press
◀ or ▶ to select the Settings/Adj. tab ( ).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
If the Display Screen indicates to replace the Maintenance Cartridge, replace the Maintenance Cartridge. If a message
is displayed indicating to check the remaining capacity of the Maintenance Cartridge, or before tasks that deplete much
of the capacity such as head cleaning or preparations to move the printer, check the remaining Maintenance Cartridge
capacity and prepare a new Maintenance Cartridge as needed. (See "Replacing the Maintenance Cartridge.") ➔ P.558
Checking the Remaining Maintenance Cartridge Capacity iPF680
User's Guide
Maintenance and Consumables Maintenance Cartridge
562

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
