Canon imagePROGRAF iPF680 User Manual

Paper not aligned with right guide.
Paper not aligned with right guide.
Cause Corrective Action
When paper was loaded, it was not aligned with the guide on the right side. Follow these step to reload a sheet.
1. Push the Release Lever back.
2. Pull out the sheet.
3. Pull the Release Lever forward.
4. Reload the sheet, aligning it with the guide on the right.
Cannot detect papr
Cannot detect papr
Cause Corrective Action
The printer could not detect the paper. Reload the paper as follows.
1. Remove the paper and press the OK button.
2. Reload the paper.
(See "Loading Sheets in the Printer.") ➔P.392
(See "Loading Rolls in the Printer.") ➔ P.373
Leading edge detection error.
Leading edge detection error.
Cause Corrective Action
The leading edge of the paper cannot be detected. Follow these step to reload a sheet.
1. Push the Release Lever back.
2. Reload the sheet straight, in the correct position.
(See "Loading Sheets in the Printer.") ➔ P.392
Paper cutting failed.
Paper cutting failed.
Cause Corrective Action
There are sheets left on the
Ejection Guide.
1.
Push the Release Lever back and remove the paper.
2. Load the paper.
3. Pull the Release Lever forward.
4. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press
the OK button.
Printing will resume, starting from the page on which the error occurred.
(See "Loading Rolls in the Printer.") ➔ P.373
There is a foreign object by
the Output Tray, obstructing
the Cutter Unit.
1. Lift the Top Cover and remove the foreign object.
2. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press
the OK button.
Printing will resume, starting from the page on which the error occurred.
You are not using the printer
under the recommended en-
vironmental conditions for
the paper.
Use the printer only where the recommended environmental conditions for the paper are met. Note that
various environmental conditions are recommended for various types of paper. For details on the recom-
mended environmental conditions for paper, see Paper Reference Guide."
(See "Displaying the Paper Reference Guide.") ➔ P.363
You are using paper that is
not compatible with automat-
ic cutting.
1. Specify Manual as the cutting method and use scissors or a cutting tool to cut the roll.
(See "Specifying the Cutting Method for Rolls.") ➔ P.386
For information about paper that is compatible with automatic cutting, see the Paper Reference
Guide.
(See "Displaying the Paper Reference Guide.") ➔ P.363
2.
Push the Release Lever back and remove the paper.
Paper not aligned with right guide. iPF680
User's Guide
Error Message Messages regarding paper
616

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
