Supported AVC Class Map and Policy Map Formats
This section descriobes the supported avc class maps and policy map formats.
Supported AVC Class Map Format
DirectionClass Map ExampleClass Map Format
Both ingress and
egress
class-map match-any NBAR-VOICE
match protocol ms-lync-audio
match protocol protocol name
Both ingress and
egress
class-map match-any NBAR-VOICE
match protocol ms-lync-audio
match dscp ef
Combination filters
Supported AVC Policy Format
QoS ActionPolicy Format
Mark and policeEgress policy based on match protocol filter
Mark and policeIngress policy based on match protocol filter
The following table describes the detailed AVC policy format with an example:
DirectionAVC Policy ExampleAVC Policy Format
Ingress and egress
policy-map MARKING-IN
class NBAR-MM_CONFERENCING
set dscp af41
Basic set
Ingress and egress
policy-map POLICING-IN
class NBAR-MM_CONFERENCING
police cir 600000
set dscp af41
Basic police
Ingress and egress
policy-map webex-policy
class webex-class
set dscp ef
police 5000000
Basic set and police
Ingress and egress
policy-map webex-policy
class webex-class
set dscp af31
police 4000000
class class-webex-category
set dscp ef
police 6000000
class class-default
set dscp <>
Multiple set and police including
default
System Management Configuration Guide, Cisco IOS XE Amsterdam 17.2.x (Catalyst 9500 Switches)
122
Configuring Application Visibility and Control in a Wired Network
Supported AVC Class Map and Policy Map Formats
