Cisco UCS C240 M5 Service Manual

APPENDIX B
Storage Controller Considerations
This appendix provides storage controller (RAID and HBA) information.
•
Supported Storage Controllers and Cables, page 129
•
Storage Controller Card Firmware Compatibility, page 131
•
RAID Backup (Supercap), page 131
•
Write-Cache Policy for Cisco 12G SAS Modular RAID Controllers, page 132
•
Mixing Drive Types in RAID Groups, page 132
•
RAID Controller Migration, page 133
•
Storage Controller Cable Connectors and Backplanes, page 133
•
Embedded SATA RAID Controller, page 137
•
For More RAID Utility Information, page 147
Supported Storage Controllers and Cables
This server supports a single, PCIe-style, SAS RAID or HBA controller that plugs into a dedicated internal
socket.
For SFF, 8-drives version only (UCSC-C240-M5S): Do not mix controller types in the server. Do not use
the embedded SATA controller and a hardware-based RAID controller card to control front-loading drives
at the same time. This combination is not supported and could result in data loss.
Note
NVMe PCIe SSDs cannot be controlled by a SAS/SATA RAID controller.Note
This server supports the RAID and HBA controller options and cable requirements shown in the following
table.
Cisco UCS C240 M5 Server Installation and Service Guide
129
