Product Manual – DOC. 8432A Crestron Pyng OS 2 for CP4-R • 155
NOTE: All of the lighting loads that have been added to the chosen room are added to a
new lighting scene at their current brightness levels.
The following settings may be configured for the lighting scene:
• Use the text box at the top of the screen to edit the lighting scene name.
• Use the provided controls to adjust the brightness levels for any lighting loads
that have been added to the scene. Lighting loads are adjusted in real time.
o Tap the filled sun button to set a lighting load to its maximum brightness
(100%).
o Tap the empty sun button to turn off a lighting load (0%).
o Tap the plus button (+) or minus button (-) to raise or lower the brightness
level incrementally for lighting loads with dimmers.
o Use the slider to adjust the brightness level manually for lighting loads with
dimmers.
NOTE: Lighting loads may also be adjusted using the dimmers or switches
configured to control the lighting load.
• Select the duration that a lighting scene fades in after being recalled and fades
out after the scene is completed.
Tap Add/Remove Loads to add lighting loads from different rooms or to remove
existing lighting loads. An
Add/Remove Loads dialog box is displayed.
Add/Remove Loads Dialog Box
