Product Manual – DOC. 8432A Crestron Pyng OS 2 for CP4-R • 165
The configuration screen for the climate event is displayed.
Scene Configuration Screen - Climate
The following settings may be configured for the climate event:
• Use the text box at the top of the screen to edit the name for the climate event.
• Event Time: Set the time that the climate event should occur using the provided
spinner menus.
• Event Days: Tap the appropriate check boxes above each day of the week to
select the days that the climate event should occur. A filled check box indicates
that the event is scheduled to occur on the associated day.
• Event Setpoints: Select the temperature set points for cooling , heating ,
and auto modes using the appropriate spinner menu.
NOTE: Depending on the selected mode, the thermostat switches to cooling
mode when the room temperature reaches the cooling set point, switches to
heating mode when the room temperature reaches the heating set point, or
maintains the auto mode set point.
• Event Status: Tap the check box to enable the event and add it to the
thermostat schedule. New events are disabled by default.
Tap Save to save the climate event or tap Cancel to cancel creating the event.
