User's Manual
244
Figure 4-153
Step 2 Draw people counting rule.
1) Click to draw people counting rule.
2) Configure parameters.
Table 4-49
Set the minimum time that the object stays until the alarm is
triggered.
Click to filter the target. Check the blue wireframe and adjust
the size of the area with the mouse.
Each rule can set 2 target filters (maximum size and minimum
size), that is, when the passing target is smaller than the minimum
target or larger than the maximum target, no alarm will be
generated. The maximum size should not be smaller than the
minimum size.
3) Click and hold the left mouse key to draw an area for people counting.
4) Click
OK
.
Step 3 Click in both
Parameters
and
Trigger
columns, and configure parameters.
Table 4-50
Select a channel from the dropdown list.
Check the box to enable the function.
Select a people counting rule type.
Click
RULE
to set statistics region, name, direction.
