User's Manual
247
Figure 4-154
Step 3 Click to draw queuing rule and area.
Step 4 Click in both
Parameters
and
Trigger
columns, and configure parameters.
Table 4-51
Select a channel from the dropdown list.
Set queue detection region.
Select Queue People No. Alarm or Queue Time Alarm.
Configure the period and in the set time range, the corresponding
configuration item will be linked to start the alarm.
The alarm device (such as lights, sirens, etc.) is connected to the
alarm output port. When an alarm occurs, the NVR device transmits
the alarm information to the alarm device.
When the alarm ends, the alarm extended for a period of time. The
time range is from 0 seconds to 300 seconds.
Select the check box. When an alarm occurs, the NVR device uploads
an alarm signal to the network (including the alarm center).
● This function is for some series products only.
● You need to set the alarm center first. For details, see "4.12.13
Alarm Center".
