User's Manual
94
The following figure is for refe
rence only.
Figure 3
-
26 Connect
cables
Step 9
Put back the
cover and fasten t
he screws on the rear panel to compl
ete the installation.
Figure 3
-
27 Fasten
screws
3.3.5 NVR608
-
64
-
4KS2/NVR608
-
128
-
4KS2/NVR608H
-
32
-
XI/NVR608H
-
64
-
XI/NVR608H
-
128
-
XI Series
Procedure
Step 1
Unlock the lo
ck on the front panel.
113
115
