User's Manual
272
5.9.9.2 Configuring Video Metadata
When a metadata alarm is triggered, the system links the corresponding camera to record videos
and logs and take snapshots. Other alarm linkage actions are not supported for video metadata.
Procedure
Step 1 Select
Main Menu
>
AI
>
Parameters
>
Video Metadata
.
Figure 5-165 Video metadata
Step 2 Select a channel and AI type.
AI by Recorder is available on select models.
Step 3 Click
Add
to add a rule.
Step 4 Select
Enable
and then set
Type
to
People Detection
,
Non-motor Vehicle Detection
or
Motor Vehicle Detection
.
Step 5 Draw detection rule.
1) Click , and then draw a detection area on the video image. Right-click the image to
stop drawing.
