Parameter Description
Status
Indicates the status of UPnP function.
●
Offline: Failed.
●
Online: Succeeded.
LAN IP
Enter IP address of router on the LAN.
After mapping succeeded, the system obtains IP address automatically.
WAN IP
Enter IP address of router on the WAN.
After mapping succeeded, the system obtains IP address automatically.
Port Mapping
List
The settings on port mapping list correspond to the UPnP port mapping list on
the router.
●
Service Name: Name of network server.
●
Protocol: Type of protocol.
●
Internal Port: Internal port that is mapped on the Device.
●
External Port: External port that is mapped on the router.
●
To avoid the conflict, when setting the external port, try to use the ports
from 1024 through 5000 and avoid popular ports from 1 through 255 and
system ports from 256 through 1023.
●
When there are several devices on the LAN, properly arrange the ports
mapping relations to avoid mapping to the same external port.
●
When establishing a mapping relationship, ensure the mapping ports are
not occupied or limited.
●
The internal and external ports of TCP and UDP must be the same and
cannot be modified.
●
Click to modify the external port.
Step 3 Click
Apply
to complete the settings.
In the browser, enter http://WAN IP: External IP port. You can visit the Device on the LAN.
5.11.12 Email
You can configure the email settings to enable the system to send the email as a notification when
an alarm event occurs.
Procedure
Step 1 Select
Main Menu
>
NETWORK
>
Email
.
To Next Page
