User's Manual
338
Parameter Description
Network Type.
Select a 3G/4G network type to distinguish between 3G/4G modules
from different vendors.
APN, Dial-up No. Main parameters of PPP dial.
Authentication Type
Select PAP, CHAP or NO_AUTH. NO_AUTH represents no
authentication for 3G/4G.
Step 3 Click
Apply
.
5.11.7 Cellular Network
Connect the Device to mobile network and view network status and traffic of the cellular network.
Prerequisites
A SIM card is inserted in the recorder.
Background Information
This function is available on select models.
Procedure
Step 1 Select
Main Menu
>
NETWORK
>
Cellular Network
>
Cellular Network
.
Step 2 Enable cellular network and configure parameters.
Figure 5-226 Configuring cellular network
Table 5-64 4G cellular network parameters
Parameter Description
NIC Name Select a NIC.
Network Type Select a network from the SIM card provider.
