User's Manual
155
5.6.7.5 EPTZ
5.6.7.5.1 Configuring EPTZ Linkage
Turn on the EPTZ linkage function on the live page. This function can simultaneously zoom in and
track multiple humans and vehicles that trigger alarms. It provides rich details and a panoramic view
at the same time.
Background Information
Some models need to configure the EPTZ linkage function in
Camera
, and then the EPTZ linkage
function will be enabled on the live page.
Procedure
Step 1 Right-click the live page, and then select
Main Menu
.
Step 2 Select
CAMERA
>
EPTZ Linkage
.
Step 3 Configure the parameters.
Figure 5-48 EPTZ linkage
Table 5-15 Parameters description
Parameter Description
Channel Select the linkage channel.
Display Mode
Select the number of tracked channels. Full screen, 1+1, 1+3 and 1+5
modes are available, and full screen is selected by default.
Linkage Track
After
Linkage Track
is enabled, intelligent events will be tracked. It is
disabled by default.
Tracking Duration
●
Custom: Select the tracking duration time manually. For example, if
you set from 30 s to 60 s, after tracking object A for 30 s, if object B
appears, the camera will start tracking object B; if no other object
appears in the process of tracking A, the camera will stop tracking
object A after 60 s.
●
Continue till object disappears: The camera will stop tracking when
the detected object disappears in the image.
