User's Manual
412
5.17.1 Settings
Procedure
Step 1 Select
Main Menu
>
POS
>
POS Setting
.
Figure 5-302 POS setting
Step 2 Configure the POS parameters.
Table 5-88 POS parameters
Parameter Description
POS Name
In the POS Name list, select the POS machine that you want to configures
settings for. Click to modify the POS name.
●
The POS name must be unique.
●
You can enter up to 21 Chinese characters or 63 English characters.
Enable Enable the POS function.
Record Channel Click to select a channel to record.
Privacy Enter the privacy contents.
Protocol Select a protocol. Different machines correspond to different protocols.
Connection Mode
Select the connection protocol type. Click , the
IP Address
window is
displayed.
In the
Source IP
box, enter the IP address (the machine that is connected to
the Device) that sends messages.
To Next Page
