Name: Dahua NVR5432-XI
Brand: Dahua
Rating: 4 (1 reviews)

To Next Page

To Previous Page

User's Manual

Figure 2-108 Rear panel

Table 2-44 Ports

No. Name No. Name

1 Power Input 2 Alarm In/Out

3 Network Port 4 USB Port

5 eSATA Port 6

HDMI Port

High-definition decoding card is not

installed in standard hardware

configuration, you can purchase as

needed.

7 VGA Port 8 AUDIO IN, RCA Connector

9 AUDIO OUT, RCA Connector 10 RS-232 Port
