140 Statistics and Diagnostics
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Dell Astute\User
Guide\Dell_Astute_Statistics_and_Diagnostics.fm
DELL CONFIDENTIAL – PRELIMINARY 8/9/16 - FOR PROOF ONLY
1
Click
Statistics and Diagnosis > Statistics.
2
Click
CPU Utilization
.
3
Select Ports or LAG in
View By.
4
Select the
Refresh Rate
to specify how frequently the statistics should be
refreshed.
The following fields are displayed:
–
Interface
— The port or LAG number.
–
Interface Status
— The status of the interface:
Up
,
Down
or
Not
Present
when no port is attached to the LAG.
–
% Interface Utilization
— Network interface utilization percentage,
based on the duplex mode of the interface.
–
% Unicast Received
— Percentage of Unicast packets received on the
interface.
–
% Non Unicast Packets Received
— Percentage of non-Unicast
packets received on the interface.
–
% Error Packets Received
— Percentage of packets with errors
received on the interface.
Diagnostics
This section describes how to perform hardware tests on the device. It
contains the following topics:
•Integrated Cable Test
• Optical Transceiver Diagnostics
•Identify
Integrated Cable Test
NOTE: This feature is not supported on x4012 devices.
Time Domain Reflectometry (TDR) technology is used to test the quality
and characteristics of a copper cable attached to a port. Cables up to 120
meters long can be tested. Cables can only be tested when the ports are in the
down state, with the exception of Approximated Cable Length test.
