Network Administration: Multicast 293

FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Dell Astute\User

Guide\Dell_Astute_Network_Admin_Multicast.fm

DELL CONFIDENTIAL – PRELIMINARY 8/9/16 - FOR PROOF ONLY

–

Ports

— Select the ports to be added to a Multicast service. Toggle a

port to

to join the port to the selected Multicast group as a

Static

port. Toggle a port to

to indicate that it is

Forbidden

to this service.

Leave the field empty if it is not involved in the VLAN.

–

LAGs

— Select the LAGs to be added to a Multicast service. Toggle a

LAG to

to join the port to the selected Multicast group as a

Static

LAG. Toggle a port to

to indicate that it is

Forbidden

to this service.

Leave the field empty if it is not involved in the VLAN.

The following table describes the codes used for the interface in this page:

Multicast Forward All

When Bridge Multicast Filtering is enabled, Multicast packets to registered

Multicast groups are forwarded to ports based on IGMP Snooping and MLD

snooping. If Bridge Multicast Filtering is disabled, all Multicast packets are

flooded to the corresponding VLAN.

You can statically (manually) configure a port to Forward All, if the devices

connecting to the port do not support IGMP and/or MLD, or the port is

connected to a neighboring Multicast router/switch.

Multicast packets, excluding IGMP and MLD messages, are always forwarded

to ports that are defined as Forward All.

The configuration affects only the ports that are members of the selected

VLAN.

To attach interfaces to a Multicast service:

Click

Network Administration > Multicast >

Multicast Forward All

Select a VLAN.

Select the Interface Type:

Port

LAG

. The status of all interfaces is

displayed.

Table 17-1. IGMP Port/LAG Members Table Control Settings

Port Control Definition

S Attaches the port to the Multicast group as static member in the static row.

The port/LAG has joined the Multicast group statically in the current row.

F Forbidden. The port cannot belong to the Multicast group.

None The port is not attached to a Multicast group, but it is also not forbidden.
