Dell X1000 Series User Manual

286 Network Administration: SNMP Monitoring
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Dell Astute\User
Guide\Dell_Astute_Network_Admin_SNMP.fm
DELL CONFIDENTIAL – PRELIMINARY 8/9/16 - FOR PROOF ONLY
Notification Filter
Notification filters determine the type of SNMP notifications that are sent to
the management station, based on the OID of the notification to be sent.
Each OID is linked to a device feature or a feature aspect.
SNMP notification filters provide the following services:
• Identification of management trap targets
•Trap filtering
• Selection of trap generation parameters
• Access control checks
After creating a notification filter, attach it to a notification recipient in the
SNMPv1,2 Notification Recipients pages.
To add a notification filter:
1
Click Switch Management > SNMP Monitoring > Notification Filter .
2 Click Edit and select Settings Icon ( ), for the New Filter configuration
page.
3 Enter the Filter Name of the new filter and save it.
4 To configure the notification filter, click Edit .
5 Select the filter in the Filter Name list.
6 Click Edit .
7 Click New Object ID Subtree and the following fields:
–
New Object Identifier Tree — Check to specify the device feature
OID included or excluded in the selected SNMP view.
•
Select from List — Select the device feature OID by using the Up
and
Down buttons to scroll through a list of all device OIDs.
or:
•
Object ID — Specify the device feature OID.
8 If required, change the notification filter type by selecting one of the
following options:
–
Included — OID traps or informs will be sent.
–
Excluded — OID traps or informs will not be sent.
