Dell X1000 Series User Manual

CLI 351
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Dell Astute\User
Guide\Dell_Astute_CLI_new.fm
DELL CONFIDENTIAL – PRELIMINARY 8/9/16 - FOR PROOF ONLY
Syntax
dir
Parameters
This command has no arguments or keywords.
Command Mode
Privileged EXEC mode
Example
Example 1. The following example displays the list of files on a flash file
system with static images. The Flash size column for all files except dynamic
image specifies the maximum allowed size. The Data size column for dynamic
images specifies the real size in the FLASH occupied by the file.
console# dir
Directory of flash:
File Name Permission Flash Size Data Size Modified
--------- ---------- ---------- --------- ---------
image-1 rw 10485760 10485760 01-Jan-2010 06:10:23
image-2 rw 10485760 10485760 01-Jan-2010 05:43:54
dhcpsn.prv -- 262144 -- 01-Jan-2010 05:25:07
syslog1.sys r- 524288 -- 01-Jan-2010 05:57:00
syslog2.sys r- 524288 -- 01-Jan-2010 05:57:00
directry.prv -- 262144 -- 01-Jan-2010 05:25:07
startup-config rw 786432 1081 01-Jan-2010 10:05:34
Total size of flash: 66322432 bytes
Free size of flash: 42205184 bytes
do
The do command executes an EXEC-level command from Global
Configuration mode or any configuration submode.

Dell X1000 Series Specifications

General

PoE	No
Management	Unmanaged
Switching Capacity	16 Gbps (8-Port), 32 Gbps (16-Port)
Forwarding Rate	11.9 Mpps (8-Port), 23.8 Mpps (16-Port)
Jumbo Frame Support	9KB
Type	Unmanaged
Ports	8
Mounting	Desktop
MAC Address Table Size	8K
Power Consumption	8.5W (16-Port)
Series	X1000 Series
