F.3 Place Dispenser into Standalone Operation from Serial Mode
(iX Fleet Fuel Control System or other Serial Fuel Control System)
NOTE: The following table shows the setting for units without price displays. Units with price displays
will look slightly different as they typically utilize all three displays.
Step 1 Turn off the power to the dispenser(s) at the breaker panel.
Step 2 Remove the front door of the dispenser and lower the display panel. The JP1
connector should be connected across both pins of the JP1 header.
Step 3 Raise the display panel and replace the front door of the dispenser.
Step 4 Turn on the power to the dispenser at the breaker panel.
Step 5 Follow the steps in the following table to change the dispenser configuration to
standalone operation.
Enter Configuration Mode
Step IRC Command Volume Display
Status
Display
1 Service engineer sign on Press <ENTER> PASS 1 [blank]
2 Enter service engineer
password
Type your service engineer password
& Press <ENTER>
PASS 2 [blank]
3 Enter service engineer
password
Type your service engineer password
& Press <ENTER>
[alternating software
version & date]
F - -
Change From Serial Mode to Standalone Mode
4 Go to Filling Mode
configuration function
Type <01> & Press <ENTER>
- - - - - - F 01
5 Go to Filling Mode parameter Pres <ENTER> again 1 (serial mode) 01.00
6 Clear display Press <#> [blank] 01.00
7 Enter standalone value
Type <2> for standalone mode & then
press <ENTER>
2 01.00
8 Return to function level Press <ENTER> again - - - - - F 01
Exit Configuration Mode
9 Go to exit function Type <0> and then Press <ENTER> - - - - - - F 00
10 Go to exit sub-function Press <ENTER> again 1 0.00
11 Clear display Press”#” [blank] 0.00
12 Exit and save changes Type <3> and then press <ENTER>
3 0.00
13 Exit configuration Press <ENTER> again
[alternating
CHAnGE StorEd]
0.00
NOTE: When you wish to return to original mode, you can follow the above steps to
remove the local authorization jumper. In the configuration, change
subfunction 01.00 back to “1”.
If dispenser is equipped with a Pulse Output Board, verify F27.00 is set to “8”.
If not, change it to “8” and leave in this setting even after converting back to
the serial mode.
