38 Dover Fueling Solutions W2940305 Rev 07 8/2019
5.1.1 Portable Tanks and Containers
Portable containers of 12 gallons (45 liters) or less shall not be filled while they are in or on a
motor vehicle. Filling portable containers, especially when they are sitting on a non-
conductive surface such as a floor mat or a plastic bedliner in the back of a pick-up truck, can
present a possible safety hazard and should be avoided as so stated in the following
WARNING:
FIRE HAZARD!
The flow of gasoline through the dispenser nozzle can produce static electricity, which can
cause a fire if gasoline is pumped into an ungrounded gasoline container. To avoid static
buildup and the possible resulting serious injury:
Place approved container on the ground. Do not fill the container in the vehicle or truck
bed.
Keep the nozzle in contact with the can or container while filling. Do not use an
automatic pump handle (latch-open) device.
5.1.2 Health Note
Be advised that petroleum fuel and fuel vapors can damage your health.
5.2 Dispenser Operation
To Dispense Product:
Step 1 If the dispenser is connected to a fuel control system, first authorize the dispenser
at the control system. Otherwise, proceed directly to step 2.
Step 2 Remove the nozzle from the nozzle holder.
Step 3 Lift the on/off nozzle hook upwards to the on position.
Step 4 The dispenser display will automatically reset to all zeros. The submersible pump
will be turned on, and then the solenoid valve in the dispenser will be opened.
Step 5 Insert the nozzle into the vehicle’s fill tank and squeeze the nozzle handle to
dispense fuel.
Step 6 After fueling is complete, lower the on/off nozzle hook lever to the down “off”
position to shut off the dispenser, and re-insert the nozzle into the holder.
NOTE: If a control system is not being used, the nozzle may be locked into the nozzle holder to
prevent unauthorized usage.
WARNING
