Step 8 For non-super-high capacity models, proceed directly to step 9.
Super-high capacity models have two meters tied to one hose. Repeat steps 4 thru
7 for the second meter. (Note: super-high capacity models can be identified by a
“2” in the third digit following the “G” in the model number; e.g., 3/G7121D.)
Step 9 Verify the accuracy by following the verification procedure in Section 4.6.2.
Step 10 Seal the calibration door (both doors if a super-high capacity model.
4.7 Voltage Test
While the dispenser is turned off, verify the incoming voltage to the dispenser is within +
10% of the rated voltage. If the voltage is not within the acceptable range, take the
appropriate corrective measures before using the dispenser. Ensure the area around the
dispenser during the test is free of vapors.
4.8 Complete Installation
Re-check the dispenser and all piping and hose connections to make sure all
connections are tight and there are not any signs of leaks.
Make sure you have completed all of the manufacturers’ test procedures for all
equipment, piping, and accessories utilized in the fuel dispensing system.
After all tests have been completed successfully, and a proper installation and operation
are verified, the tank and piping may be covered and the conduit openings should be
appropriately sealed.
The installer should make sure the following items are left with the fuel site owner:
o All documentation and manuals
o Infrared Remote Control
o Local Authorization Jumper if connected to a fuel control system
4.9 Complete Warranty Registration
Follow the instructions in Appendix L and complete the Warranty Registration.
