60 Dover Fueling Solutions W2940305 Rev 07 8/2019
Pulser A1 LED
Authorization A1 LED
Reset Complete A1 LED
Authorization Input
Connector
(Field Wiring)
Reset Complete Connector
(Field Wiring)
Pulse Output
(Field Wiring)
Authorization A1 & A2
(Internal Cabling)
Pulser A1 & B1
(Internal Cabling)
Reset Complete A1 & B1
(Internal Cabling)
C.2 Pulse Output Interface Board Layout
