Dover Wayne Select S1 User Manual

W2940305 Rev 07 8/2019 Dover Fueling Solutions 41
Gallons
Status
5.7 Dispenser Statistics & Diagnostics
5.7.1 General
 The Select Series provides a variety of statistical and diagnostic information. This section
covers the electronic totalizers. For a complete list of all available information, reference
Appendix E.
 The statistics and diagnostics can be accessed without
opening the dispenser. The interface is handled through an
infrared remote control (IRC) that is shipped with the
dispenser. To use the IRC, point it at the dispenser displays
from within a distance of a couple of feet and press the
desired keys. The nozzle hook on/off lever must be in the
“off” position to access the statistics and diagnostics.
 Responses to the IRC commands are shown on the
dispenser displays. Statistic function and subfunction
numbers are shown in the Status display and their
corresponding values are shown in the Gallons/Liters
display. Reference Figure 5-1.
NOTE: The following table shows the setting for units without price displays. Units with price
displays will look slightly different as they typically utilize all three displays.
Figure 5-2 Infrared
Remote Control (IRC)
Figure 5-1 In this example, the Status display shows subfunction 33.01
(change service engineer password) with “PASS” shown in the Gallons
display since the actual password is not shown for security reasons.
