Enterasys D-Series User Manual

set lldp port tx-tlv
5-26 Discovery Protocol Configuration
Parameters
all AddsalloptionalTLVstotransmittedLLDPDUs.
port‐desc PortDescriptionoptionalbasicLLDPTLV.ValuesentisifDescrobject
definedinRFC2863.
sys‐name SystemNameoptionalbasicLLDPTLV.Valuesentisthe
administrativelyassignednameforthesystem.
sys‐desc SystemDescriptionoptionalbasicLLDPTLV.Valuesentis
sysDescr
objectdefinedinRFC3418.
sys‐cap SystemCapabilitiesoptionalbasicLLDPTLV.Foranetwork
connectivitydevice,valuesentcanbe bridge and/orrouter.
mgmt‐addr ManagementAddressoptionalbasicLLDPTLV.ValuesentisIPv4
addressofhostinterface.
vlan‐id PortVLANIDIEEE802.1ExtensionsTLV.Valuesentis
portVLAN
ID(PVID).
stp SpanningTreeinformationdefinedbyProtocolIdentityIEEE802.1
ExtensionsTLV.IfSTPisenabledontheport,valuesentincludes
versionofprotocolbeingused.
lacp LACPinformationdefinedbyProtocolIdentityIEEE802.1
ExtensionsTLV.IfLACPisenabledontheport,valuesentincludes
versionofprotocolbeingused.
gvrp GVRPinformationdefinedbyProtocolIdentityIEEE802.1
ExtensionsTLV.IfLACPisenabledontheport,valuesentincludes
versionofprotocolbeingused.
mac‐phy MAC‐PHYConfiguration/StatusIEEE802.3ExtensionsTLV.Value
sentincludestheoperationalMAUtype,duplex,andspeedofthe
port.
poe PowerviaMDIIEEE802.3ExtensionsTLV.Valuessentinclude
whetherpairselectioncanbecontrolledonport,andthepowerclass
suppliedbytheport.OnlyvalidforPoE‐enabledports.
link‐aggr LinkAggregationIEEE802.3ExtensionsTLV.Valuessentindicate 
whetherthelinkassociatedwiththisportcan
beaggregated,
whetheritiscurrentlyaggregated,andifaggregated,theaggregated
portidentifier.
max‐frame MaximumFrameSizeIEEE802.3ExtensionsTLV.Valuesent
indicatesmaximumframesizeoftheport’sMACandPHY.
med‐cap LLDP‐MEDCapabilitiesTLV.Valuesentindicatesthecapabilities
(whetherthedevicesupportslocationinformation,extendedpower

viaMDI)andDeviceType(networkconnectivitydevice)ofthe
sendingdevice.
med‐loc LLDP‐MEDLocationIdentificationTLV.ValuesentistheECSELIN
valueconfiguredontheport.
med‐poe LLDP‐MEDExtendedPowerviaMDITLV.Valuessentincludethe
PowerLimit(totalpowertheportiscapableof
sourcingovera
maximumlengthcable)andthepowerpriorityconfiguredonthe
port.OnlyvalidforPoE‐enabledports.
port‐string Specifiestheportorrangeofportstobeaffected.
