Fresenius Medical Care 4008 S Service Manual

Chapter 5: Setup / service program
Fresenius Medical Care 4008 S (Version V10) SM-EN 7/01.13 5-35
Navigation
5.1.4.3 Reading the analog inputs of CPU 1
 Explanation
 Part 1
Menu display Description
CPU1: RD ANALOG INP. (see Part 1 page 5-35)
CPU2: RD ANALOG INP. (see Part 2 page 5-37)
CPU1: RD DIGITAL INP (see Part 3 page 5-38)
CPU2: RD DIGITAL INP (see Part 4 page 5-44)
CPU1: WR ANALOG OUTP (see Part 5 page 5-47)
CPU2: WR ANALOG OUTP (see Part 6 page 5-48)
CPU1: WR DIGIT. OUTP (see Part 7 page 5-49)
CPU2: WR DIGIT. OUTP (see Part 8 page 5-54)
CPU1: COMBINATION (see Part 9 page 5-57)
HPU (see Part 10 page 5-58)
BPM (see Part 11 page 5-59)
Display (field ): ADC digits
Display (field ): Analog voltage (in 0.1 V), converted to the value at the input of P.C.B. LP 633-5
Menu item Description
E: CPU1_PWR_WD Voltage for watchdog monitoring
5 V, IC 27/26, ADC 107
(4.5–5.5 V)
E: CPU1_P_CONC Not used
0 V, IC 27/27, ADC 0
E: CPU1_P_VEN Venous pressure
0–12 V, IC 27/28, ADC 0–255
E: CPU1_BPR_VEN Venous blood pump rate
0-10 V, IC 27/1, ADC 0-215
(Line diameter: 8 mm)


I: CPU1_PWR_WD back to menu ?
Conf
key
Conf
key
CPU1: RD ANALOG INP.
