Chapter 11: Functional description
11-12 Fresenius Medical Care 4008 S (Version V10) SM-EN 7/01.13
11.1.1.11 Battery test
Test description Check the battery voltage under load.
LP 632
CPU 2
LP 633
Input
board
board
LP 634
Output
board
LP 630
Mother-
DATA BUS
Akku
Rückmeldung/Acknowledgement
Testgenerierung/Generation of Test
X632/B27
X632/B28
X634R/C23
TESTBATT
X639/A10
X639/A2
X639/A3
X633L/B21
U_ACCU
X639/A4
(16 - 22V)
Power
Supply
4008
LP 922
Display
board
X1631/20a
X1631/21a
CPU 1
L P1631
X631/A20 X631/A21
