Chapter 11: Functional description

11-48 Fresenius Medical Care 4008 S (Version V10) SM-EN 7/01.13

 Legend (HPU wiring diagram)

X A1 UF pump (22), flow pump (21),

degassing pump (29),

Air separation pump (97)

X A2 valves (V24, V24B, V26, V30, V41, V43, V84,

V91, V112)

X A3 balancing chamber valves (V31–V38), valves

(V86, V87)

X A4 CDS, V99, V100, V102, V126, V130

X A5 V183, V188, V189, V9, compressor (185)

CO1 Concentrate pump, conductivity cell

BI1 Bicarbonate pump

X R1 OCM_NTC4

X 2 NTC2

X 3 NTC3

X 5 Float switch

X 6 Level sensor (6)

X 7 Conductivity measuring cell

X 8 Dialysate pressure transducer (1)

X 9 Reed contact (10) concentrate

X 10 CDS pressure switch

X11 bibag

X12 bibag

NTC (133)

X13 bibag

conductivity cell

X14 NTC109

X 15 OCM conductivity cell (110)

X S1 Dialysate pressure transducer 2 (182)

XS2 NC

XS3 NC

XS4 NC

X S5 Concentrate level sensor (202)

X S6 NTC INDI (308)

X S7 INDI conductivity cell (309)
