PRIMERGY RX100 S3 User’s Guide
5
Operations after OS Installation
5.7 LAN Driver Advanced Setup
[Intel
®
PROSet]
"Intel
®
PROSet" is a tool for configuring details on the LAN driver. This is used in the
following cases.
• Use the Teaming function between LAN cards or between a LAN card and the
onboard LAN
• Setup a VLAN using a LAN card
• Perform the other advanced setups of a LAN card
Use of BACS
 Use BACS (pg.157) to perform the following advanced setups of the onboard LAN:
• Use the teaming (load balance) function between onboard LANs.
• Setup a VLAN using the onboard LAN
• Perform the other advanced setups of the onboard LAN
5.7.1 Intel
®
PROSet Installation
If the tabs such as [Link], [Teaming] and [VLANs] are not displayed in the property of LAN adapters
which can be selected from the [Device Manager], install Intel
®
PROSet according to the following
installation procedures:
1 Execute the following file contained in the ServerStart Disc 1 CD-ROM.
For Windows Server 2003 x64
[CD-ROM drive]:\Tools\GENERAL\Intel\ProSet\Ws03_32e\InstPROSet.EXE
For Windows Server 2003 / Windows 2000 Server
[CD-ROM drive]:\Tools\GENERAL\Intel\ProSet\Ws03xp2k\InstPROSet.EXE
2 Click [OK].
3 Click [Next].
4 Click [Accept].
5 Confirm only the following two items are checked and click [Next].
• Intel(R) PROSet for Windows Device Manager
• Advanced Network Services
6 Click [Install].
