186
Chapter 7 Installing Internal Options
7.4.2 Installable Expansion Cards and Notes
This section explains expansion cards that can be installed and provides notes on installation.
■ Installable Expansion Cards
Up to two expansion cards listed on the following table can be installed in the server.
■ Location and Order of Expansion Card Installation
For expansion cards, use the PCI slots in accordance with the order indicated in the following table.
Follow the Installation order shown in the table when installing the cards and drivers.
If you install expansion cards after changing the installation order, they will not function properly.
-: Not installable.
table: List of Installable Expansion Cards
Installable expansion card (Model name)
Number
of cards
Remarks
Remote Service Board (PG-RSB103L) 1
2
SCSI Ctrl U160 lp (PG-1301L) 1
For an internal hard disk unit and an external
SCSI option (Ultra 160 SCSI, LowProfile)
Eth. Ctrl 1000-BASE-T Cu lp (PG-1892L) 2
2
1000BASE-T, LowProfile
Eth. Ctrl 1000-BASE-SX Fibre LC lp
(PG-1882L)
2 1000BASE-SX, LowProfile
Eth. Ctrl 2x1000-BASE-T Cu (PG-1862) 1 1000BASE-T, Dual Port
Eth. Ctrl 1000-BASE-T Cu (PG-1852) 1 1000BASE-T
table: Installation Order and Slots for Expansion Cards
Installable expansion card (Model name)
PCI slot
Installation Order
1 2
Remote Service Board (PG-RSB103L) - 1 1
SCSI Ctrl U160 lp (PG-1301L) 2 1 2
Eth. Ctrl 1000-BASE-T Cu lp (PG-1892L) 2 1 3
Eth. Ctrl 1000-BASE-SX Fibre LC lp (PG-1882L) 2 1 4
Eth. Ctrl 2x1000-BASE-T Cu (PG-1862) 1 - 5
Eth. Ctrl 1000-BASE-T Cu (PG-1852) 1 - 6
