PRIMERGY RX100 S3 User’s Guide
Installing Internal Options
7
7.5.2 How to Install the Internal CD-ROM Drive Unit
 The DVD-ROM drive unit package includes parts which are not used for drive installation.
1 Turn off the power and remove the top cover.
"7.2 Removing and Attaching the Top Cover" (pg.178)
2 Touch a metal part of the server to discharge static electricity.
3 Loosen the screws of the dummy unit, and remove the dummy unit.
Slide the dummy unit backward and lift it up.
Be sure to keep the removed dummy units for later use.
4 Install the CD-ROM drive unit.
Insert the stopper latches of the CD-ROM drive unit into slots of the server.
Screw
Dummy unit
㪚㪛㪄㪩㪦㪤㩷㪻㫉㫀㫍㪼㩷㫌㫅㫀㫋
㪠㫅㫊㪼㫉㫋㩷㫃㪸㫋㪺㪿㪼㫊
