229
PRIMERGY RX100 S3 User’s Guide
8
Configuring Hardware and Utilities
8.2.6 Configuring and Deleting the Array System
■ How to Configure the Array System
This section describes how to configure the array system using onboard SCSI controller. Only level
RAID1 is configured.
Configure the array of two internal hard disks of the same model. The array system cannot be
configured on a different kind of hard disk.
If you connect any hard disk units with usage history to this server, format them at low level on another
system before connecting them to the server. For low-level formatting, refer to the manual supplied
with the other system to be used.
1 Start the SCSI Setup Utility.
2 Select the [<RAID Properties>] submenu from the [<Adapter Properties>]
menu, and press the [Enter] key.
[RAID Properties] submenu window appears.
3 Select [Array Disk?] of which [SCSI ID] is [0], and press the [+] key to change
[No] to [Yes].
When the [+] key is pressed, the following message appears.
4 Press the [F3] key.
5 Select [Array Disk?] of which [SCSI ID] is [1], and press the [+] key to change
[No] to [Yes].
The following message may appear which indicates that the data are in the target disk. The
data in the hard disk are deleted when the array system configured.
Press the [Delete] key to delete data and configure the array system.
6 Press the [Esc] key to display the [Exit] menu.
7 Select [<Save changes then exit this menu>], press the [Enter] key and save
the settings.
F3 - Keep Date(Create 2 disk array)
Delete - Erase Disk(Create 2 to 6 disk array)
WARNING: Data on disk will be LOST!
Hit DELETE if data loss OK, any other key to can-
cel
To Next Page
