Page 4-64 LMM for the Kodiak 100
190-02102-00 Rev.4
4.7.6 GTS Troubleshooting
Consult GTS-IM4 (190-00993-03) for additional trouble information using
the GTS 8XX Install Tool.
Table 4-8. GTS Troubleshooting
Problem Cause Solution
Unit does not come on
Data failed message
Improper wiring; circuit
breaker open.
Improper configuration.
• Ensure power is properly
wired to the GTS and the
circuit breaker is closed.
• Ensure the remote power
discretes (P8003-18,36).
• Verify using the USB tool
the GTC Processor is
configured correctly for the
desired display
.
GTS Install Tool won't
display any pages
Improper wiring; circuit
breaker open.
• Ensure USB is properly
wired to the GTS and the
circuit breaker is closed.
Traffic Display
erroneously indicates TA
at aircraft position
Suppression bus I/O
fault.
• Check the mutual
suppression line to ensure
it is connected to the
correct pins at the GTS as
well as the installed
transponder. Ensure there
are no fractures in the wire,
and the suppression line is
functioning properly.
No Audio alerts Improper wiring; Volume
not set correctly.
• Ensure the audio is
properly wired from the
GTS and volume is not set
too low.
Calibration Fault Factory calibration
invalid.
• If the unit fails to go into
operate mode then return
to Garmin for service.
