LMM for the Kodiak 100 Page 6-1
190-02102-00 Rev. 4
6 RELOADING SOFTWARE AND CONFIGURATION
This section provides procedures to be followed after equipment is replaced. These
instructions define necessary procedures to be followed for situations where original
equipment was reinstalled as well as for situations where new equipment (new serial
number) is installed.
If the technician skips reloading of a replaced LRU, an ‘LRU replacement
detected’ message is shown on the GDU in normal mode. This message
persists until the LRU software reloading procedure is performed. The
‘LRU replacement detected’ message may not be displayed if there are
existing Manifest error or Configuration error messages.
The procedures in this section can be used to correct problems relating to MANIFEST
errors, CONFIG (configuration errors), and LRU REPLACEMENT messages that show
up after the replacement of an LRU.
Baseline system software and configuration must already be loaded and functioning
correctly before reloading software and configuration to an LRU that has been replaced.
In the event of an upload failure, cycle power to the system and attempt the procedure
again. In the event of continued failures stop performing the procedures in this section
and perform the procedure described in Section 3, Loading System Software And
Configuration, using the Transaction Log (on the Transaction Log Page) as a guide for
what options were previously installed on the system.
Testing and/or calibration is required to confirm proper operation of the LRU after
software and configuration is loaded (Section 7). The procedures in this section only
support software and configuration reloading. Refer to the Kodiak 100 Pilot's Guide for
instructions on loading databases and subscription related items.
The procedure in this section cannot be used to replace PFD1. Use the full procedure as
outlined in Section 3.
6.1 Applicability and Limitations
The system keeps track of features that have been activated using baseline, options,
and enablement cards. When an LRU is replaced, the system will ensure the associated
feature set remains available.
Reloading described in this section only supports replacement of LRUs with the same
model number. For example, a GIA 64W-20 should only be replaced with GIA 64W-20
model in order to utilize the procedures. Reference Section 3 for procedures on how to
perform a full software/configuration load in the event of a LRU model number change.
The procedures in this section cannot be used if a software update is being carried out
on the system. Reference Section 3 for procedures on how to perform a full software/
configuration load in the event of a software upgrade.
