LMM for the Kodiak 100 Page 5-11
190-02102-00 Rev.4
5.2.11 GTX 345R Transponder Replacement
Unit Part Number: GTX 345R 011-03303-01
Installation Manual Part Number: 190-01499-02
TURN OFF AIRCRAFT POWER BEFORE REMOVAL OR REINSTALLA-
TION OF THE TRANSPONDER. UNPLUG ANY AUXILIARY POWER
SUPPLY
1. To Remove:
a) Insert a 3/32” hex drive tool into the access hole in the front of the unit.
b) Turn the hex drive tool counterclockwise until it stops.
c) Pull the unit from the rack, using the spring loaded tab on the front of the unit.
2. To Reinstall:
a) Visually inspect the connectors on the back of the rack to make sure there are
no bent or damaged pins. Repair any damage found.
b) Insert a 3/32” hex drive tool into the access hole in the front of the unit.
c) Turn the hex drive tool counterclockwise until it stops.
d) Slide the unit into the rack until it stops. The unit will appear to stick out of the
rack approximately 3/8”.
e) Insert a 3/32” hex drive tool into the access hole in the front of the unit.
f) Push on the left side of the unit and turn the hex drive tool clockwise until it
stops. Do not apply more than 8 in-lbs of torque on the hex tool to seat the
unit.
5.2.12 GTP 59 Outside Air Temperature Probe Replacement
Unit Part Number: 011-00978-00
Installation Manual Part Number: 190-00313-00
1. To Remove:
a) Using a deep well socket to hold the probe in place on the outside of the air-
craft, along with a 9/16” open end wrench, loosen the GTP 59 mounting nut.
b) Remove the mounting nut, sealing washer, and the GTP 59.
