LMM for the Kodiak 100 Page 5-15
190-02102-00 Rev.4
5.2.15 GSM 86 Servo Gearbox
Unit Part Numbers: 011-01904-04 (pitch, roll, yaw and pitch trim)
Installation Manual: 190-00303-83
Keep Part the protective covers (part numbers 145-00807-00 and 145-
00808-00) installed for as long as practical and use care while handling
before and during installation of the autopilot servo actuator and servo
mount to avoid foreign object/debris contamination. If foreign object/debris
contamination of either the servo actuator or servo mount is suspected,
immediately return the contaminated unit(s) to Garmin for repair.
Do not disassemble the servo actuator or servo mount. There is no require-
ment or provision for routine maintenance, lubrication, or field repair of the
servo actuator or servo mount. Servo actuators and servo mounts in need
of repair may be returned to Garmin for service.
Do not insert any foreign object into the openings located in the mating sur-
faces of either the autopilot servo actuator or servo mount.
1. To Remove:
a) Remove the desired servo(s).
b) De-rig the flight control cabling or chain (refer to the servo installation
drawings for removal details).
c) Use a socket or open-wrench to loosen and remove the servo attachment
bolts.
d) Carefully remove the servo mount.
2. To Reinstall:
a) Follow the installation instructions provided in the respective servo installation
drawings.
b) If no other maintenance is to be performed, reinstall the servo(s).
