Page 4-90 LMM for the Kodiak 100
190-02102-00 Rev.4
4.7.11 GDL 69A SXM Satellite Radio Receiver Troubleshooting
4.7.11.1 GDL 69A SXM System Messages
Table 4-18 lists GDL 69A SXM related system messages, possible causes, and
recommended actions.
4.7.11.2 Activating SiriusXM Services
Before SiriusXM Weather and SiriusXM Satellite Radio can be used, the services must
be activated by providing SiriusXM customer service the coded IDs unique to the
installed GDL 69A SXM.
SiriusXM Satellite Radio (audio) and SiriusXM Weather (data) services each have coded
IDs. The Data and Audio Radio IDs must be provided to activate the weather and
entertainment subscriptions, respectively. These IDs are in the following locations:
• The SiriusXM Info Screen on Touchscreen Controllers
• The XM Satellite Radio Activation Instructions included with the unit
• the label on the back of the GDL 69A SXM Datalink Receiver
Contact Garmin Aviation Support if the Audio and Data Radio IDs cannot be located.
SiriusXM uses the coded IDs to send an activation signal to enable the system to receive
weather data and/or audio entertainment programming.
Table 4-18. GDL 69A SXM System Messages
System Message Cause Recommended Actions
GDL69 CONFIG GDL 69 configuration
error.
• Reload configuration to the
GDL.
• If the fault persists, check
the configuration module
wiring for faults and replace
if necessary.
• If the fault persists, replace
the master configuration
module.
• If the fault persists, replace
the GDL.
GDL69 FAIL A failure has been
detected in the GDL 69
is unavailable.
• Replace the GDL.
GDL69 MANIFEST GDL 69 software
mismatch.
• Load the correct software.
