Garmin G1000 Line Maintenance Manual

______________________________________________________________________________
____________________________________________________________________________
LMM for the Kodiak 100 Page 5-3
190-02102-00 Rev.4
5.2.2 GMA1360D/GMA1347 Audio Panel Replacement
Unit Part Number: 011-03568-20 or 011-00809-00
Installation Manual Part Number: 190-03813-00 or 190-00303-20
CAUTION
Switch off No. 2 GMA when No. 2 GIA is being replaced. If No. 2 GMA was
not switched off, then reload the config for No. 2 GMA.
1. To Remove:
a) Using a 3/32” hex drive tool, turn the hex nut counterclockwise until the GMA
1347 is unlocked from its location.
b) Carefully remove the GMA 1360D/1347 from its rack.
2. To Reinstall:
a) Visually inspect the connectors to ensure there are no bent or damaged pins.
Repair any damage.
b) Insert a 3/32” hex drive tool into the access hole and turn the mechanism
90°counterclockwise to insure the correct position before placing the unit in
the rack.
c) Gently push the unit into the rack and engage the connectors.
d) Insert a 3/32” hex drive tool into the access hole and turn the mechanism
clockwise until the unit is firmly seated in the rack, avoiding excessive
tightening.
