LMM for the Kodiak 100 Page 2-29
190-02102-00 Rev.4
2.4 CONFIGURATION MODE NAVIGATION
The user can navigate through different pages and page groups in Configuration Mode
using the FMS knob
2.5 SOFTWARE FILES
Software files are defined by part number and version number in SN21-01 Kodiak 100
G1000 Software Configurations and Updates. Each system LRU reports the software
version it currently contains to the user in two places.
• Normal System Mode: The Aux - System Status page lists each LRU and the
reported software version.
• Configuration Mode: The System Status page (System page group) reports more
detailed LRU information, including software version, part number, and LRU status.
• Software files are loaded to LRUs from the PFD System Upload page in
configuration mode.
Table 2-6. Data Transmission Indicators
The LRU is online and reports the item located next to the indicator
box is communicating.
The LRU is online, and reports the item located next to the indicator
box is not communicating.
The LRU is not reporting a status for the item located next to the
indicator box. This may be because the data is not available, not
applicable, or not expected.
The LRU is not reporting status for the item located next to the
indicator box. This may be because the data is not available or is
not expected.
‘True’ condition; i.e., necessary conditions have been met in order
to activate the item.
‘False’ condition; i.e., necessary conditions have not been met in
order to activate the item.
‘High’ condition; i.e., the system expects a high voltage or a high
resistance input to trigger the item (fan operation, etc.).
‘Low’ condition; i.e., the system expects a low voltage or a low
resistance input to trigger the item (fan operation, etc.).
