LMM for the Kodiak 100 Page 5-1
190-02102-00 Rev.4
5 LRU REPLACEMENT
This section contains Garmin LRU installation and removal instructions. Garmin
installation manual part numbers are listed at the beginning of each of the sub-sections
for technician reference. The procedures contained in this section are for reference only
and do not supersede the installation and removal procedures in the Kodiak 100 AMM.
5.1 Accessing LRUs
Refer to the Kodiak 100 AMM for information about gaining access to LRUs.
Certain LRU connectors include Garmin backshell assemblies. Garmin
backshells gives the installer the ability to easily terminate shield grounds
at the backshell housing. Refer to the Jackscrew Backshell Installation
Instructions (Garmin P/N 190-00313-11) for backshell assembly instruc-
tions.
5.2 Replacement Procedures
Always make sure that aircraft power is off when removing or installing an LRU.
Disconnect any auxiliary power supplies when performing LRU replacement.
This section lists reference documents which contain additional information
for installing Garmin LRUs. The technician should read all of this relevant
reference material before removing and reinstalling an LRU.
Software and configuration must be loaded to an LRU after it has been
replaced. Testing is also required.
