Page 5-4 LMM for the Kodiak 100
190-02102-00 Rev.4
5.2.3 GIA 64W/63W Integrated Avionics Unit Replacement
Installation Manual Part Number: 190-01912-00 or 190-00303-05
Unit Part Number: 011-03711-00 or 011-01105-20
Garmin Reference Documents
• 190-00848-00 GA 35, GA 36, and GA 37 Antenna Installation Instructions
• 190-00355-02 GDL 69/69A Installation Manual
• 190-00522-01 GA 55A, GA 56A, GA 57 Installation Instructions
• 190-00483-01 GA 56W Antenna Installation Instructions
• 004-00287-00 Antenna Minimum Performance Specification for the Garmin GPS/
WAAS Receiver System
1. To Remove:
a) Loosen the Phillips screw (or pull on the D-Ring and twist counter-clockwise
90°, for units with a D-Ring).
b) Unlock the handle and remove the unit from the rack.
The install screw is designed with a ratcheting socket that resists turning
counterclockwise, unless pushed in. This ensures the engagement screw
cannot loosen under vibration.
2. To Reinstall:
a) Carefully slide the GIA into the rack. Ensure the orientation of the unit allows
for engagement of the locking stud in the channel on the rack. The unit can
only be installed in one direction.
b) Push the GIA lever down towards the bottom of the unit. This engages the
locking stud with the dogleg slot and locks unit into the rack. If there is
excessive resistance, do not force the unit.
c) Lock the handle into the GIA body and tighten the Phillips screw (or push in
the D-Ring and twist clockwise 90°, for units with a D-Ring).
