GE Power Management
489 Generator Management Relay 4-71
4 SETPOINT PROGRAMMING 4.12 S11 ANALOG I/O
4
4.12.2 ANALOG INPUTS 1 TO 4
Table 4–8: ANALOG OUTPUT PARAMETER SELECTION
PARAMETER NAME RANGE / UNITS STEP DEFAULT
MIN. MAX
IA Output Current 0.00 to 20.00 × FLA 0.01 0.00 1.25
IB Output Current 0.00 to 20.00 × FLA 0.01 0.00 1.25
IC Output Current 0.00 to 20.00 × FLA 0.01 0.00 1.25
Av
g
. Output Current 0.00 to 20.00 × FLA 0.01 0.00 1.25
Ne
g
. Seq. Current 0 to 2000% FLA 1 0 100
Avera
g
ed Gen. Load 0.00 to 20.00 × FLA 0.01 0.00 1.25
Hottest Stator RTD –50 to +250°C or –58 to +482°F 1 0 200
Hottest Bearin
g
RTD –50 to +250°C or –58 to +482°F 1 0 200
Ambient RTD –50 to +250°C or –58 to +482°F 1 –50 60
RTDs 1 to 12 –50 to +250°C or –58 to +482°F 1 –50 250
AB Volta
g
e 0.00 to 1.50 × Rated 0.01 0.00 1.25
BC Volta
g
e 0.00 to 1.50 × Rated 0.01 0.00 1.25
CA Volta
g
e 0.00 to 1.50 × Rated 0.01 0.00 1.25
Volts/Hertz 0.00 to 2.00 × Rated 0.01 0.00 1.50
Frequency 0.00 to 90.00 Hz 0.01 59.00 61.00
Neutral Volt. (3rd) 0 to 25000 V 0.1 0.0 45.0
Avera
g
e Volta
g
e 0.00 to 1.50 × Rated 0.01 0.00 1.25
Power Factor 0.01 to 1.00 lead/la
g
0.01 0.8 la
g
0.8 lead
Reactive Power (Mvar) –2.00 to 2.00 × Rated 0.01 0.00 1.25
Real Power –2.00 to 2.00 × Rated 0.01 0.00 1.25
Apparent Power 0.00 to 2.00 × Rated 0.01 0.00 1.25
Analo
g
Inputs 1 to 4 –50000 to +50000 1 0 50000
Tachometer 0 to 7200 RPM 1 3500 3700
Thermal Capacity Used 0 to 100% 1 0 100
Current Demand 0.00 to 20.00 × FLA 0.01 0.00 1.25
Mvar Demand 0.00 to 2.00 × Rated 0.01 0.00 1.25
MW Demand 0.00 to 2.00 × Rated 0.01 0.00 1.25
MVA Demand 0.00 to 2.00 × Rated 0.01 0.00 1.25

ANALOG INPUT 1

[ENTER] for more
ANALOG INPUT1:
Disabled
Range: Disabled, 4-20 mA, 0-20 mA, 0-1 mA
ANALOG INPUT1 NAME:
Analog I/P 1
Range: 12 alphanumeric characters
ANALOG INPUT1 UNITS:
Units
Range: 6 alphanumeric characters
ANALOG INPUT1
MINIMUM: 0
Range: –50000 to 50000 in steps of 1
ANALOG INPUT1
MAXIMUM: 100
Range: –50000 to 50000 in steps of 1
BLOCK ANALOG INPUT1
FROM ONLINE: 0 s
Range: 0 to 5000 sec. in steps of 1
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
