GE 489 User Manual

5-22 489 Generator Management Relay
GE Power Management
5.6 A5 EVENT RECORDER 5 ACTUAL VALUES
5
5.6 A5 EVENT RECORDER 5.6.1 EVENT RECORDER

[ENTER] for E65535
No Event
TIME OF E65535:
00:00:00.0
Range: hour:minutes:seconds
Seen only if there has been an event.
DATE OF E65535:
Jan. 01, 1992
Range: month day, year
Seen only if there has been an event.
ACTIVE SETPOINT
GROUP E65535: 1
Range: 1, 2
TACHOMETER
E65535: 3600 RPM
Range: 0 to 3600 RPM. Seen only if a Digital Input is
programmed as Tachometer
A: 0 B: 0
C: 0 A E65535
Range: 0 to 999999 A. Represents current measured
from the output CTs. Seen only if there has been
an event.
a: 0 b: 0
c: 0 A E6
Range: 0 to 999999 A. Represents differential current.
Seen only if the differential element is enabled.
NEG. SEQ. CURRENT
E65535: 0% FLA
Range: 0 to 2000% FLA
Seen only if there has been an event.
GROUND CURRENT
E65535: 0.00 A
Range: 0.00 to 20000.0 A. Not seen if the GROUND CT
is programmed as None.
Vab: 0 Vbc: 0
Vca: 0 V E65535
Range: 0 to 50000 V. Not seen if VT CONNECTION is
programmed as None.
FREQUENCY
E65535: 0.00 Hz
Range: 0.00 to 90.00 Hz. Not seen if VT CONNECTION
is programmed as None.
NEUTRAL VOLT (FUND)
E65535: 0.0 V
Range: 0.0 to 25000.0 V.
Seen only if there is a neutral voltage transformer.
NEUTRAL VOLT (3rd)
E65535: 0.0 V
Range: 0.0 to 25000.0 V
Seen only if there is a neutral voltage transformer.
Vab/Iab E65535:
0.0
Ω
sec. 0°
Range: 0.0 to 6553.5
Ω
sec., 0 to 359°. Seen only if the
Loss of Excitation element is Enabled.
REAL POWER (MW)
E65535: 0.000
Range: 0.000 to ±2000.000 MW. Not seen if VT
CONNECTION is programmed as None
REACTIVE POWER Mvar
E65535: 0.000
Range: 0.000 to ±2000.000 Mvar. Not seen if VT
CONNECTION is programmed as None
APPARENT POWER MVA
E65535: 0.000
Range:0.000 to 2000.000 MVA. Not seen if VT
CONNECTION is programmed as None
HOTTEST STATOR
RTD#1: 0°C E65535
Range: –50 to +250°C. Seen only if 1 or more RTDs are
programmed as Stator.
HOTTEST BEARING
RTD#7: 0°C E65535
Range: –50 to +250°C. Seen only if 1 or more RTDs are
programmed as Bearing.
HOTTEST OTHER
RTD#11: 0°C E65535
Range: –50 to +250°C. Seen only if 1 or more RTDs are
programmed as Other.
AMBIENT
RTD#12 0°C E65535
Range: –50 to +250°C. Seen only if 1 or more RTDs are
programmed as Ambient.
ANALOG INPUT 1
E65535: 0.0 Units
Range: –50000 to 50000
Seen only if the Analog Input is in use.
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
