6.5 DNP POINT LISTS 6 COMMUNICATIONS
6
6.5.3 BINARY / FROZEN COUNTER (OBJECTS 20/21)
The counters cannot be cleared with the Freeze/Clear function codes (9/10). Instead, the control relay output block
points can be used to clear groups of counters. There is only one copy of each counter, so clearing a counter via
Modbus or the front panel display causes the corresponding DNP counter point to be cleared and vice-versa.
POINT LIST FOR: BINARY COUNTER (OBJECT 20)
FROZEN COUNTER (OBJECT 21)
INDEX ROLLOVER
POINT
DESCRIPTION
0 50,000 Number of Breaker Operations
1 50,000 Number of Thermal Resets
2 50,000 Number of Trips (total)
3 50,000 Number of Digital Input Trips
4 50,000 Number of Sequential Trips
5 50,000 Number of Field-Breaker Discrepancy Trips
6 50,000 Number of Tachometer Trips
7 50,000 Number of Offline Overcurrent Trips
8 50,000 Number of Phase Overcurrent Trips
9 50,000 Number of Negative Sequence Overcurrent Trips
10 50,000 Number of Ground Overcurrent Trips
11 50,000 Number of Phase Differential Trips
12 50,000 Number of Undervoltage Trips
13 50,000 Number of Overvoltage Trips
14 50,000 Number of Volts/Hertz Trips
15 50,000 Number of Phase Reversal Trips
16 50,000 Number of Underfrequency Trips
17 50,000 Number of Overfrequency Trips
18 50,000 Number of Neutral Overvoltage (Fundamental) Trips
19 50,000
Number of Neutral Undervoltage (3
rd
Harmonic) Trips
20 50,000 Number of Reactive Power Trips
21 50,000 Number of Reverse Power Trips
22 50,000 Number of Underpower Trips
23 50,000 Number of Stator RTD Trips
24 50,000 Number of Bearing RTD Trips
25 50,000 Number of Other RTD Trips
26 50,000 Number of Ambient RTD Trips
27 50,000 Number of Thermal Model Trips
28 50,000 Number of Inadvertent Energization Trips
29 50,000 Number of Analog Input 1 Trips
30 50,000 Number of Analog Input 2 Trips
31 50,000 Number of Analog Input 3 Trips
32 50,000 Number of Analog Input 4 Trips
33 50,000 Number of Loss of Excitation Circle 1 Trips
34 50,000 Number of Loss of Excitation Circle 2 Trips
35 50,000 Number of Ground Directional Trips
36 50,000 Number of High Set Phase Overcurrent Trips
37 50,000 Number of Distance Zone 1 Trips
38 50,000 Number of Distance Zone 2 Trips
