489 Generator Management Relay 5-15
5 ACTUAL VALUES 5.3 A2 METERING DATA
5
5.3.4 TEMPERATURE
The current level of the 12 RTDs will be displayed here. If the RTD is not connected, the value will be "No RTD". If no RTDs
are programmed in the
S7 RTD TEMPERATURE
setpoints menu, the
THIS FEATURE NOT PROGRAMMED
flash message will
appear when an attempt is made to enter this group of messages.

TEMPERATURE

[ENTER] for more
HOTTEST STATOR RTD
RTD#1: 40°C
Range: –50 to 250°C, No RTD
Seen only if at least 1 RTD programmed as Stator
RTD #1
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD. Not seen if RTD
programmed as None. Value reflects the RTD
Name as programmed
RTD #2
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #3
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #4
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #5
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #6
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #7
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #8
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #9
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #10
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #11
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #12
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
