Page #127 background imageLoading...
Page #127 background image
GE Power Management
489 Generator Management Relay 5-13
5 ACTUAL VALUES 5.3 A2 METERING DATA
5
5.3.2 VOLTAGE METERING
Measured voltage parameters will be displayed here. The V/Hz measurement is a per unit value based on Vab voltage/
measured frequency divided by VT nominal/nominal system frequency. Polar coordinates for measured phase and/or line
voltages are also shown using Va (wye connection) or Vab (open delta connection) as a zero angle reference vector. In the
absence of a voltage signal (Va or Vab), IA output current is used as the zero angle reference vector.
If
VT CONNECTION TYPE
is programmed as "None" and
NEUTRAL VOLTAGE TRANSFORMER
is "No" in S2 SYSTEM, the follow-
ing flash message will appear when an attempt is made to enter this group of messages.
îš„
VOLTAGE METERING
îš„
[ENTER] for more
Vab: 0 Vbc: 0
Vca: 0 Volts
Range: 0 to 50000 V. Not seen if VT CONNECTION is
programmed as None.
AVERAGE LINE
VOLTAGE: 0 Volts
Range: 0 to 50000 V. Not seen if VT CONNECTION is
programmed as None.
Van: 0 Vbn: 0
Vcn: 0 Volts
Range: 0 to 50000 V. Seen only if VT CONNECTION is
programmed as Wye.
AVERAGE PHASE
VOLTAGE: 0 Volts
Range: 0 to 50000 V. Seen only if VT CONNECTION is
programmed as Wye.
LINE A-B VOLTAGE:
0 V 0° Lag
Range: 0 to 50000 V, 0 to 359°. Not seen if VT
CONNECTION is programmed as None.
LINE B-C VOLTAGE:
0 V 0° Lag
Range: 0 to 50000 V, 0 to 359°. Not seen if VT
CONNECTION is programmed as None.
LINE C-A VOLTAGE:
0 V 0° Lag
Range: 0 to 50000 V, 0 to 359°. Not seen if VT
CONNECTION is programmed as None.
PHASE A-N VOLTAGE:
0 V 0° Lag
Range: 0 to 50000 V, 0 to 359°. Seen only if VT
CONNECTION is programmed as Wye.
PHASE B-N VOLTAGE:
0 V 0° Lag
Range: 0 to 50000 V, 0 to 359°. Seen only if VT
CONNECTION is programmed as Wye.
PHASE C-N VOLTAGE:
0 V 0° Lag
Range: 0 to 50000 V, 0 to 359°. Seen only if VT
CONNECTION is programmed as Wye.
PER UNIT MEASUREMENT
OF V/Hz: 0.00
Range: 0.00 to 2.00. Not seen if VT CONNECTION is
programmed as None.
FREQUENCY:
0.00 Hz
Range: 0.00 to 90.00 Hz. Not seen if VT CONNECTION
is programmed as None.
NEUTRAL VOLTAGE
FUND: 0.0 V
Range: 0.0 to 25000.0 V. Seen only if there is a neutral
voltage transformer.
NEUTRAL VOLTAGE
3rd HARM: 0.0 V
Range: 0.0 to 25000.0 V. Seen only if there is a neutral
voltage transformer.
TERMINAL VOLTAGE
3rd HARM: 0.0 V
Range: 0.0 to 25000.0 V. Seen only if VT CONNECTION
is programmed as Wye.
IMPEDANCE Vab / Iab
0.0
Ω
sec. 0°
Range: 0.0 to 6553.5
Ω
sec., 0 to 359°
THIS FEATURE
NOT PROGRAMMED
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
