GE Power Management
489 Generator Management Relay 5-5
5 ACTUAL VALUES 5.2 A1 STATUS
5
Any active or latched alarms may be viewed here.
5.2.4 TRIP PICKUPS
BREAKER FAILURE
ALARM: Active
Range: Active, Latched. Active if condition that caused
the alarm is still present.
TRIP COIL MONITOR
ALARM: Active
Range: Active, Latched. Active if condition that caused
the alarm is still present.
VT FUSE FAILURE
ALARM: Active
Range: Active, Latched. Active if condition that caused
the alarm is still present.
CURRENT DEMAND
ALARM: 1053 A
Range: 1 to 999999 A.
The running current demand is shown here.
MW DEMAND
ALARM: 50.500
Range: –2000.000 to +2000.000 MW
Current Running MW Demand is shown here
Mvar DEMAND
ALARM: –20.000
Range: –2000.000 to +2000.000 Mvar
Current Running Mvar Demand is shown here
MVA DEMAND
ALARM: 20.000
Range: 0 to 2000.000 MVA
Current Running MVA Demand is shown here
ANALOG I/P 1
ALARM: 201 Units
Range: –50000 to +50000. Reflects the Analog Input 1
Name. The Analog Input level is shown here.
ANALOG I/P 2
ALARM: 201 Units
Range: –50000 to +50000. Reflects the Analog Input 2
Name. The Analog Input level is shown here.
ANALOG I/P 3
ALARM: 201 Units
Range: –50000 to +50000. Reflects the Analog Input 3
Name. The Analog Input level is shown here.
ANALOG I/P 4
ALARM: 201 Units
Range: –50000 to +50000. Reflects the Analog Input 4
Name. The Analog Input level is shown here.
ALARM, 489 NOT
INSERTED PROPERLY
If the 489 chassis is only partially engaged with the
case, this service alarm appears after 1 sec. Secure the
chassis handle to ensure that all contacts mate properly
489 NOT IN SERVICE
Simulation Mode
Range: Not Programmed, Simulation Mode, Output
Relays Forced, Analog Output Forced, Test
Switch Shorted
IRIG-B FAILURE
ALARM: Active
Range: Active. Seen only if IRIG-B is enabled and the
associated signal input is lost.
GEN. RUNNING HOURS
ALARM: 1000 h
Range: 0 to 1000000 hrs. Seen only if the Running
Hour Alarm is enabled.
îš„
TRIP PICKUPS
îš„
[ENTER] for more
Input A
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip. Reflects Input Name as
programmed. Seen only if function assigned is an
input.
Input B
PICKUP: Not Enabled
Range: see Input A PICKUP above
Input C
PICKUP: Not Enabled
Range: see Input A PICKUP above
Input D
PICKUP: Not Enabled
Range: see Input A PICKUP above
Input E
PICKUP: Not Enabled
Range: see Input A PICKUP above
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
