GE 489 User Manual

5-8 489 Generator Management Relay
GE Power Management
5.2 A1 STATUS 5 ACTUAL VALUES
5
The trip pickup messages may be very useful during testing. They will indicate if a trip feature has been enabled, if it is inac-
tive (not picked up), timing out (picked up and timing), active trip (still picked up, timed out, and causing a trip), or latched tip
(no longer picked up, but had timed out and caused a trip that is latched). These values may also be particularly useful as
data transmitted to a master device for monitoring.
5.2.5 ALARM PICKUPS
ANALOG I/P 4
PICKUP: Not Enabled
Range: see ANALOG I/P 1 above

ALARM PICKUPS

[ENTER] for more
Input A
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm. Reflects Input Name as
programmed. Seen only if function is an input.
Input B
PICKUP: Not Enabled
Range: see Input A PICKUP
Input C
PICKUP: Not Enabled
Range: see Input A PICKUP
Input D
PICKUP: Not Enabled
Range: see Input A PICKUP
Input E
PICKUP: Not Enabled
Range: see Input A PICKUP
Input F
PICKUP: Not Enabled
Range: see Input A PICKUP
Input G
PICKUP: Not Enabled
Range: see Input A PICKUP
Input G ALARM
STATUS: Active
Range: see Input A PICKUP
TACHOMETER
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm. Seen only if function is an input.
OVERCURRENT
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
NEG. SEQ. OVERCURRENT
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
GROUND OVERCURRENT
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
PHASE DIFFERENTIAL
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
GROUND DIRECTIONAL
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
UNDERVOLTAGE
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
OVERVOLTAGE
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
VOLTS/HERTZ
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
UNDERFREQUENCY
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Alarm,
Latched Alarm.
MESSAGE
ESCAPE
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
