4D and Multi-plane Modes
6-44 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Touch panel and rotaries
This section describes only the Multi-plane mode controls. See
‘Image controls’ on page 5-49 for 2D, Color and TVI modes
image controls
Trackball
The trackball has multiple functions. The trackball functions are organized in
several functional groups.
The function selected is displayed in the lower right corner of the screen.
• Press Select to toggle between the trackball functions within the active functional
group. Groups with several functions are marked with a + symbol.
• Press Trackball to toggle between the functional groups.
The functions available are:
Group 1 (Live):
• Pos: in Bi-plane, tilts the scan plane 2 (white) around the top of the sector.
• Angle 1: adjusts the angle between the scan planes 2 (white) and scan plane 1
(yellow). Scan plane 2 is rotated around the crossing line between the scan
planes. Scan plane 1 is fixed.
• Angle 2: adjusts the angle between the scan planes 3 (green) and scan plane 1
(yellow). Scan plane 1 is fixed. Available in Tri-plane only.
Group 1 (Zoom):
• Pos: moves the zoom area.
• Size: resizes the zoom area.
Group 2 (Color/TVI modes):
• Pos: moves the color sector. In Bi-plane CFM mode, if scan plane 1 (yellow) is
selected as reference scan plane, both color sectors are moved. If scan plane 2
(white) is selected as reference scan plane its color sector is moved
independently. In Tri-plane CFM mode, all ROI are moved at the same time.
• Size: resizes the color ROI. All sectors are resized at the same time.
Group 1 (Freeze/Replay):
• Speed: adjusts cine replay speed.
• Scroll: scrolls through a cineloop (in Freeze).
4D & MP
The 4D and MP buttons can be used as arrows ‘<‘ and ‘>’ to toggle between the left
and right halves of Dual Screen. This works for all probes except 4D - 6VT and
6VT-D.
Bi-plane / Tri-plane
Toggles between Bi-plane and Tri-plane mode.
Reference Plane
Toggles the reference plane between the scan planes. The reference plane may
also be selected using the trackball when the Pointer trackball tool selected.
