Customize Configuration
12-84 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Step attributes
Scan Assist Pro allows the user to program the steps in an exam
and to program certain attributes for each step. The attributes
are what give the Scan Assist Pro Protocol behavior. The tables
below provide a description of all attributes.
General attributes
Name Input Description
Step name Any text Name of the step that appears in the
Scan Assist Pro window.
Advance on Store Advance to the next step after pressing
Store on the Control panel.
Store & Unfreeze Advance to the next step after pressing
Store and Unfreeze on the Control
panel.
Store & user
selection
Advance to next step after pressing
Store on the Control panel and Down
arrow on the keyboard.
Instructions Any text Notes displayed in the Scan Assist Pro
window when the step is active.
Hint: the probe and application required
for this Protocol should be entered in
the Instruction field of the first step.
Optional An optional step is given a check mark
during Protocol execution even if no
image is acquired.
